High-efficiency chargers engineered for E-Rickshaw and E-Auto lithium battery systems
CLN-Energy IP67 vehicle chargers are designed to efficiently charge lithium-ion batteries across a range of electric vehicles, including rickshaws, autos, forklifts, golf carts, and more. Engineered for tough conditions, these rugged chargers (available in 1200W to 3300W models) offer over 90% efficiency and are built to withstand harsh outdoor environments. Backed by a 3-year warranty, they provide reliable, long-term performance. For indoor applications, the 1200W IP20 model offers the same advanced charging technology with a 2-year warranty. All models are equipped with comprehensive safety features to ensure secure and efficient charging.
Reverse Battery
Mains High Voltage
Mains Over Current
Thermal Protection
CLN-Energy IP67 vehicle chargers are designed to efficiently charge lithium-ion batteries across a range of electric vehicles, including rickshaws, autos, forklifts, golf carts, and more. Engineered for tough conditions, these rugged chargers (available in 1200W to 3300W models) offer over 90% efficiency and are built to withstand harsh outdoor environments. Backed by a 3-year warranty, they provide reliable, long-term performance. For indoor applications, the 1200W IP20 model offers the same advanced charging technology with a 2-year warranty. All models are equipped with comprehensive safety features to ensure secure and efficient charging.
Reverse Battery
Mains High Voltage
Mains Over Current
Thermal Protection
CLN-Energy IP67 vehicle chargers are designed to efficiently charge lithium-ion batteries across a range of electric vehicles, including rickshaws, autos, forklifts, golf carts, and more. Engineered for tough conditions, these rugged chargers (available in 1200W to 3300W models) offer over 90% efficiency and are built to withstand harsh outdoor environments. Backed by a 3-year warranty, they provide reliable, long-term performance. For indoor applications, the 1200W IP20 model offers the same advanced charging technology with a 2-year warranty. All models are equipped with comprehensive safety features to ensure secure and efficient charging.
Reverse Battery
Mains High Voltage
Mains Over Current
Thermal Protection
IP20 chargers efficiently power lithium-ion batteries in rickshaws, autos, forklifts, golf carts, and more. The rugged IP67 models (1200W–3300W) are ≥90% efficient, built for harsh environments, and come with a 3-year warranty. The 1200W IP20 model, designed for indoor use and includes a 2-year warranty. Both feature advanced safety protections
Read More Download CatalougeReverse Battery
Mains High Voltage
Mains Over Current
Thermal Protection
Specification | 1200 Watt | 1500 Watt | 3000 Watt |
---|---|---|---|
Input Voltage Range | 200~240VAC; 50/60Hz | 170-270 VAC L+N+E 50Hz | 85-270 VAC L+N+E 50Hz |
Output Power (W) | 1200 | 1500 | 3300 |
Charging Current (A) | 20 | 25 | 50 |
Efficiency | ≥90% | ≥90% | ≥90% |
Indications | External LED Indicator | External LED Indicator | External LED Indicator |
Power Factor | ≥0.99 | ≥0.99 | ≥0.99 |
Control System | CAN / CC CV | CAN / CC CV | CAN / CC CV |
Topology | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC |
Weight approx. (kg) | 2.5 | 2.8 | 6.0 |
Ingress Protection | IP 67 | IP 67 | IP 67 |
Working Temperature (°C) | -30 to 65 | -30 to 65 | -30 to 65 |
Warranty & Reliability | 3 Years | 3 Years | 3 Years |
Specification | 1200 Watt | 1500 Watt | 3000 Watt |
---|---|---|---|
Input Voltage Range | 200~240VAC; 50/60Hz | 170-270 VAC L+N+E 50Hz | 85-270 VAC L+N+E 50Hz |
Output Power (W) | 1200 | 1500 | 3300 |
Charging Current (A) | 20 | 25 | 50 |
Efficiency | ≥90% | ≥90% | ≥90% |
Indications | External LED Indicator | External LED Indicator | External LED Indicator |
Power Factor | ≥0.99 | ≥0.99 | ≥0.99 |
Control System | CAN / CC CV | CAN / CC CV | CAN / CC CV |
Topology | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC |
Weight approx. (kg) | 2.5 | 2.8 | 6.0 |
Ingress Protection | IP 67 | IP 67 | IP 67 |
Working Temperature (°C) | -30 to 65 | -30 to 65 | -30 to 65 |
Warranty & Reliability | 3 Years | 3 Years | 3 Years |
Specification | 1200 Watt | 1500 Watt | 3000 Watt |
---|---|---|---|
Input Voltage Range | 200~240VAC; 50/60Hz | 170-270 VAC L+N+E 50Hz | 85-270 VAC L+N+E 50Hz |
Output Power (W) | 1200 | 1500 | 3300 |
Charging Current (A) | 20 | 25 | 50 |
Efficiency | ≥90% | ≥90% | ≥90% |
Indications | External LED Indicator | External LED Indicator | External LED Indicator |
Power Factor | ≥0.99 | ≥0.99 | ≥0.99 |
Control System | CAN / CC CV | CAN / CC CV | CAN / CC CV |
Topology | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC | Active PFC + Half Bridge LLC |
Weight approx. (kg) | 2.5 | 2.8 | 6.0 |
Ingress Protection | IP 67 | IP 67 | IP 67 |
Working Temperature (°C) | -30 to 65 | -30 to 65 | -30 to 65 |
Warranty & Reliability | 3 Years | 3 Years | 3 Years |
Specification | Value |
---|---|
Max Output Power | 1200 Watt |
CV Voltage Range (V) | 53–84 |
CC Current Range (A) | 5–22 |
CC Current Tolerance (A) | CC Setting ± 0.5 |
CV Voltage Tolerance (V) | CV Setting ± 0.3 |
Efficiency | 91% Typical |
Input Power Factor | Active PF Correction, PF > 0.98, ITHD < 5% |
Mains Operating Range (Hz) | 40 to 60 |
Ingress Protection | IP 20 |
Max Input Current | 7.5A (Output Current De-Rated at Low Mains to Limit Max Input Current) |
Visual Indication | LED Based |
Charging Operation Temperature (°C) | 0–45 |
An IP67 rating indicates a high level of protection against dust and water. Devices with this rating are completely dust-tight and can withstand temporary immersion in water up to 1 meter for 30 minutes.
Our charger is designed to support LFP (Lithium Iron Phosphate) batteries and is compatible with all models offered by us.
We use various Anderson connectors based on the battery model, including SB-50, SBS-75X, and SB-120. Other connector types can also be provided as per specific requirements.
Our EV chargers require minimal maintenance—primarily keeping the exterior clean and regularly inspecting the cables for wear or damage.
An IP20 rating indicates basic protection against solid objects larger than 12.5 mm , but no protection against water. These chargers are intended for indoor use in clean, dry environments.
IP20 chargers are suitable for indoor use in dry and dust-free environments. In contrast, IP67 chargers are designed for rugged outdoor conditions, offering complete protection against dust and temporary immersion in water.
Yes, our chargers feature an automatic cut-off function that stops charging once the battery is fully charged, preventing overcharging and extending battery life.
Yes, Our charger can be used with multiple batteries, provided they have the same voltage and current specifications.
