Scalable microgrid solutions with 1-5 MWh BESS for grid-independent, sustainable power operations
CLN Energy’s Microgrid Solution—also known as a distributed energy island system—seamlessly integrates local power generation, energy storage, photovoltaic (PV) systems, and smart load control into a unified, self-reliant power network. Designed for flexibility, it can operate independently or in sync with the main grid. Ideal for remote areas, islands, and off-grid locations, this 5.015 MWh Battery Energy Storage System (BESS) delivers high-capacity, stable, and scalable power. It ensures energy availability, reduces reliance on fossil fuels, and enables sustainable, grid-independent operations.
Modular and Scalable
Multiple Protection Systems
Efficient Installation and Commissioning of AC/DC Integrated System.
Intelligent Operation and Maintenance.
High Energy Density for Flexible Layout and Expansion
CLN Energy’s Microgrid Solution—also known as a distributed energy island system—seamlessly integrates local power generation, energy storage, photovoltaic (PV) systems, and smart load control into a unified, self-reliant power network. Designed for flexibility, it can operate independently or in sync with the main grid. Ideal for remote areas, islands, and off-grid locations, this 5.015 MWh Battery Energy Storage System (BESS) delivers high-capacity, stable, and scalable power. It ensures energy availability, reduces reliance on fossil fuels, and enables sustainable, grid-independent operations.
Modular and Scalable
Multiple Protection Systems
Efficient Installation and Commissioning of AC/DC Integrated System.
Intelligent Operation and Maintenance.
High Energy Density for Flexible Layout and Expansion
CLN Energy’s Microgrid Solution—also known as a distributed energy island system—seamlessly integrates local power generation, energy storage, photovoltaic (PV) systems, and smart load control into a unified, self-reliant power network. Designed for flexibility, it can operate independently or in sync with the main grid. Ideal for remote areas, islands, and off-grid locations, this 5.015 MWh Battery Energy Storage System (BESS) delivers high-capacity, stable, and scalable power. It ensures energy availability, reduces reliance on fossil fuels, and enables sustainable, grid-independent operations.
Modular and Scalable
Multiple Protection Systems
Efficient Installation and Commissioning of AC/DC Integrated System.
Intelligent Operation and Maintenance.
High Energy Density for Flexible Layout and Expansion
CLN Energy’s Microgrid Solution—also known as a distributed energy island system—seamlessly integrates local power generation, energy storage, photovoltaic (PV) systems, and smart load control into a unified, self-reliant power network. Designed for flexibility, it can operate independently or in sync with the main grid. Ideal for remote areas, islands, and off-grid locations, this 5.015 MWh Battery Energy Storage System (BESS) delivers high-capacity, stable, and scalable power. It ensures energy availability, reduces reliance on fossil fuels, and enables sustainable, grid-independent operations.
Modular and Scalable
Multiple Protection Systems
Efficient Installation and Commissioning of AC/DC Integrated System.
Intelligent Operation and Maintenance.
High Energy Density for Flexible Layout and Expansion
Parameters / Model | BESS-1045-0.5C |
---|---|
Battery Module | |
Cell Capacity (Ah) | 314 |
Battery Pack | 1P52S |
Module Voltage (V) | 166.4 |
Module Power (kWh) | 52.2496 |
IP Class | IP67 |
Battery Rack | |
Nos. of Modules | 4 |
Cluster Nominal Voltage (V) | 665.6 |
Voltage Range (V) | 582.4–748.8 |
Single Battery Rack Power (kWh) | 208.99 |
Battery Container | |
Nos. of Battery Clusters (pcs) | 5 |
Battery System Energy (kWh) | 1045 |
Battery Cabin Dimension (WxDxH) | 6058x2438x2896 |
Cooling Method | Liquid cooling |
IP Class | IP54 |
Compliant with Standards | |
Battery | IEC62619, UL1973, UL9540A, UN38.3 |
Parameters / Model | BESS-2073-0.5C |
---|---|
DC Side Parameters | |
Cell Capacity (Ah) | 100 |
Module Structure | 3P18S |
Module Quantity in Single Cluster | 20 pcs |
Nos. of Battery Clusters | 6 pcs |
Battery System Power (kWh) | 2073 |
Voltage Range (V) | 1008 ~ 1278 |
AC Side Parameters | |
Rated Grid Voltage (kW) | 6 × 200 |
Wiring Mode (V) | 690 |
Rated Grid Frequency | 3W + PE |
Rated AC Power (Hz) | 50/60 |
Isolation Mode | No isolation transformer |
System Level Parameters | |
Operating Temperature (°C) | -30 ~ 55 |
Ambient Humidity | 0 ~ 95% (no condensation) |
Working Altitude (m) | 2000 |
Communication Method | Ethernet, RS485, optional 4G/5G mobile communication |
Protection Level | IP54 |
Cooling Method | Liquid cooling |
Noise (dB) | ≤65 |
Fire Protection System |
Heptafluoropropane / Perfluorohexanone compartment level / Aerosol ten water fire protection + Combustible gas detection + Explosion-proof ventilation system |
Size (WxDxH) (mm) | 6058 × 2438 × 2896 |
Weight (T) | 24 |
Certifications | |
Cluster | IEC62619, UL1973, UL9540A, UN38.3 |
PCS | UL1741, EN50549, VDE4110, GB/T34120, GB/T36547 |
Parameters / Model | BESS-3340-0.5C |
---|---|
DC Side Parameters | |
Cell Capacity (Ah) | 314 |
Module Structure | 1PS2S |
Module Quantity in Single Cluster | 8 pcs |
Nos. of Battery Clusters | 8 pcs |
Battery System Power (kWh) | 3340 |
Voltage Range (V) | 1164.8 ~ 1476.8 |
AC Side Parameters | |
Rated Grid Voltage (kW) | 8 × 200 |
Wiring Mode (V) | 690 |
Rated Grid Frequency | 3W + PE |
Rated AC Power (Hz) | 50 / 60 |
Isolation Mode | No isolation transformer |
System Level Parameters | |
Operating Temperature (°C) | -30 ~ 55 |
Ambient Humidity | 0 ~ 95% (no condensation) |
Working Altitude (m) | 2000 |
Communication Method | Ethernet, RS485, optional 4G/5G mobile communication |
Protection Level | IP54 |
Cooling Method | Liquid cooling |
Noise (dB) | ≤65 |
Fire Protection System | Heptafluoropropane / Perfluorohexanone compartment level / Aerosol ten water fire protection + combustible gas detection + explosion-proof ventilation system |
Size (W×D×H) (mm) | 6058 × 2438 × 2896 |
Weight (T) | 30 |
Cluster Certifications | IEC62619, UL1973, UL9540A, UN38.3 |
PCS Certifications | UL1741, EN50549, VDE4110, GB/T34120, GB/T36547 |
Parameters / Model | BESS-5015-0.5C |
---|---|
Battery Module | |
Cell Capacity (Ah) | 314 |
Battery Pack | 1P52S |
Module Voltage (V) | 166.4 |
Module Power (kWh) | 52.2496 |
IP Class | IP67 |
Battery Rack | |
Nos. of Modules (pcs) | 8 |
Cluster Nominal Voltage (V) | 1331.2 |
Voltage Range (V) | 1164.8 – 1476.8 |
Single Battery Rack Power (kWh) | 417.997 |
Battery Container | |
Nos. of Battery Clusters (pcs) | 12 |
Battery System Energy (kWh) | 5015 |
Battery Cabin Dimension (W×D×H) mm | 6058 × 2438 × 2896 |
Weight (T) | ≤43 |
Cooling Method | Liquid Cooling |
IP Class | IP54 |
Compliant with Standards | |
Battery | IEC62619, UL1973, UL9540A, UN38.3 |
It provides grid balancing, frequency regulation, voltage support, and stores excess energy from renewables to stabilize the grid.
We deliver flexible solutions from 500 kW to 5MMW, tailored for transmission and distribution networks.
Yes, Our BESS is ideal for solar, wind, and hybrid projects to manage intermittency and ensure grid compliance.
Yes, we provide end to end solution along with long-term O&M.
Our systems meet UL, IEC, BIS and UN and other regulatory requirements for safety and performance.
